Reconcile Guide

This tool empowers users to efficiently identify discrepancies and variations in data when comparing the source with the Databricks target.

Execution Pre-Set Up

1. Setup the configuration file:

Once the installation is done, a folder named .lakebridge will be created in the user workspace's home folder. To process the reconciliation for specific table sources, we must create a config file that gives the detailed required configurations for the table-specific ones. The file name should be in the format as below and created inside the .lakebridge folder.

recon_config_<SOURCE>_<CATALOG_OR_SCHEMA>_<REPORT_TYPE>.json

Note: For CATALOG_OR_SCHEMA , if CATALOG exists then CATALOG else SCHEMA

eg:

source_type	catalog_or_schema	report_type	file_name
databricks	tpch	all	recon_config_databricks_tpch_all.json
source1	tpch	row	recon_config_source1_tpch_row.json
source2	tpch	schema	recon_config_source2_tpch_schema.json

Refer to Reconcile Configuration Guide for detailed instructions and example configurations

2. Setup the connection properties

Lakebridge-Reconcile manages connection properties by utilizing secrets stored in the Databricks workspace. Below is the default secret naming convention for managing connection properties.

Note: When both the source and target are Databricks, a secret scope is not required.

Default Secret Scope: lakebridge_data_source

source	scope
snowflake	lakebridge_snowflake
oracle	lakebridge_oracle
databricks	lakebridge_databricks
mssql	lakebridge_mssql
synapse	lakebridge_synapse

Below are the connection properties required for each source:

Snowflake

sfUrl = https://[acount_name].snowflakecomputing.com
account = [acount_name]
sfUser = [user]
sfPassword = [password]
sfDatabase = [database]
sfSchema = [schema]
sfWarehouse = [warehouse_name]
sfRole = [role_name]
pem_private_key = [pkcs8_pem_private_key]
pem_private_key_password = [pkcs8_pem_private_key]

note

For Snowflake authentication, either sfPassword or pem_private_key is required. Priority is given to pem_private_key, and if it is not found, sfPassword will be used. If neither is available, an exception will be raised.

When using an encrypted pem_private_key, you'll need to provide the pem_private_key_password. This password is used to decrypt the private key for authentication.

Oracle

user = [user]
password = [password]
host = [host]
port = [port]
database = [database/SID]

MS SQL Server (incl. Synapse)

user = [user]
password = [password]
host = [host]
port = [port]
database = [database/SID]
encrypt = [true/false]
trustServerCertificate = [true/false]

3. Databricks permissions required

• User configuring reconcile must have permission to create Data Warehouses
• Additionally, the user must have USE CATALOG and CREATE SCHEMA permission in order to deploy metadata tables and dashboards that are created as part of the Reconcile output. If there is a pre-existing schema, the 'create volumes' permission is also required.

Execution

You can execute the reconciliation process by executing the below command in a notebook cell.

from databricks.labs.lakebridge import __version__
from databricks.sdk import WorkspaceClient

from databricks.labs.lakebridge.reconcile.trigger_recon_service import TriggerReconService
from databricks.labs.lakebridge.reconcile.exception import ReconciliationException

ws = WorkspaceClient(product="lakebridge", product_version=__version__)


try:
  result = TriggerReconService.trigger_recon(
            ws = ws,
            spark = spark, # notebook spark session
            table_recon = table_recon, # previously created
            reconcile_config = reconcile_config # previously created
          )
  print(result.recon_id)
  print(result)
except ReconciliationException as e:
    recon_id = e.reconcile_output.recon_id
    print(f" Failed : {recon_id}")
    print(e)
except Exception as e:
    print(e.with_traceback)
    raise e
    print(f"Exception : {str(e)}")

For more details, refer to the Reconcile Notebook documentation.
